5-axis technology and mobility in new CMM

To help companies meet tolerances and achieve repeatability, AIMS Metrology, an original equipment manufacturer (OEM) of coordinate measuring machines, has introduced the Revolution Series HB Shop Floor CMM. Designed and built around Renishaw 5-axis technology, the Revolution HB is the only mobile 5-axis CMM on the market.

“Speed is critical for manufacturers today,” says AIMS Co-owner Mark Gearding. “Parts are becoming more complex with tighter tolerances and customer lead times are shrinking. Part inspections can sometimes take two to three days using conventional methods. The Revolution HB is able to cut inspection time from days to minutes for many applications such as aerospace components. Best of all, manufacturers gain speed without sacrificing accuracy.”

Constructed with a polymer-cast base and a roll-around stand with casters that can be locked in place, the Revolution HB is easy to move. The machine runs on standard 110 volt power, so the need for shop air is eliminated. Built-in vibration resistance, mechanical bearings and thermal stability give the Revolution HB the durability it needs to withstand the rigors of shop floor use. The CMM features a Renishaw PH20 probe head which provides superior accuracy and repeatability and performs three times faster than conventional probe heads.

AIMS was founded in 2009 to equip the industry with the tools to perform accurate, flexible three-dimensional inspection for in-process and post process parts.  In 2015 the Dayton, Ohio-based OEM launched its line of Revolution LM and HB series coordinate measuring machines designed and engineered to introduce and bring Renishaw 5-axis measurement technology to the shop floor and the laboratory. AIMS’ Revolution line of CMMs are exclusively supported by Renishaw technology through probe heads, touch probes, scanning probes, incremental encoder scale systems, change racks, styli, controls, and Modus software. Faster measuring speeds, enhanced accuracy, higher throughput and lower cost of ownership make the Revolution series products especially suited for the quality control process demands of efficiency-driven manufacturers and the growing number of smart factories and automated operations. In addition to matching customer requirements with the right turnkey CMM system, AIMS provides installation, service/support and training. Machine retrofits and refurbished equipment are also available.
